SpiralVeyor SV-Series
![All-purpose spiral conveyor for medium to large products](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/SpiralVeyor_SV-560x_.jpg)
![Spiral conveyor handling secondary packaged products and cases in logistics](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_28-560x_.jpg)
![Spiral conveyor from AmbaFlex in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_14-560x_.jpg)
![Spiral conveyor suitable for boxes](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_15-560x_.jpg)
![AmbaFlex's spiral conveyor SV series wrapped in plastic](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_16-560x_.jpg)
![Three spiral conveyor's from AmbaFlex placed in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_17-560x_.jpg)
![Spiral conveyor placed in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_18-560x_.jpg)
![Multiple Spiral Conveyors installed in a large warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_19-560x_.jpg)
![Two of Ambaflex's spiral conveyor SV-Series](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_12-560x_.jpg)
![Spiral Conveyor from AmbaFlex in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_29-560x_.jpg)
![Spiral Conveyor lifting Corona boxes](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_20-560x_.jpg)
![Two of Ambaflex's Spiral Conveyors](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_21-560x_.jpg)
![Spiral conveyor SV series handling a box in logistics](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_22-560x_.jpg)
![Spiral conveyor sv-series in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_24-560x_.jpg)
![Illuminated Spiral Conveyor from AmbaFlex](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_25-560x_.jpg)
![Spiral Conveyor from Ambaflex](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_30-560x_.jpg)
![Four Spiral conveyor SV-series side by side in a warehouse](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_26-560x_.jpg)
![A spiral conveyor from Ambaflex lifting a crate](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_27-560x_.jpg)
![Spiral Conveyor handling boxes in logistics](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_SV-560x_.jpg)
![Puleva milk processed in logistics using the Spiral Conveyor](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_9-560x_.jpg)
![Spiral Conveyor from AmbaFlex lifting blue crates](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_Totes_Cartons-560x_.jpg)
![Spiral conveyor SV-series from AmbaFlex lifting orange crates](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_Totes-560x_.jpg)
![Spiral conveyor SV series from AmbaFlex outside](https://cdn.ambaflex.com/uploads/SpiralVeyor/SpiralVeyor SV/AmbaFlex_Spiral_Conveyor_SV_high-560x_.jpg)
Industries
Solutions
The SpiralVeyor SV is the all-purpose spiral conveyor for medium to large sized products. It is ideal for handling secondary packed products and cases in logistics and is used for multiple functions ranging from elevation up to accumulation.
The lateral roller system patented by AmbaFlex is simple and reliable, and renders controls and sensors superfluous. The continuous motion represents the perfect solution for the
exacting situations involved with unstable products and high production speeds. With its installed base of thousand machines worldwide (including demanding multinational clients), the AmbaFlex SpiralVeyor SV sets the standard for industry.
Suitable for goods:
Cartons, containers, trays, bottlepacks, bags, crates and totes
Details
- Belt width range: 300-600 mm | 12-24"
- Multi-belt: 1-3 parallel belts
- Load range: per belt, up to 50 kg/m | 34 lb/ft
- Speed range: standard up to 60 m/min | 200 fpm
- Elevation: virtually unlimited, commonly per drive system 15 m | 50 ft
- Belt length: up to per drive system 60 m | 200 ft
SpiralVeyor SV Series | |||
---|---|---|---|
Single Belt | Belt width | No.Tracks | Footprint |
SV 300-900 | 300 mm / 12" | 1 | 1240 mm / 4' - 1" |
SV 400-1300 | 400 mm / 16" | 1 | 1740 mm / 5' - 9" |
SV 400-1800 | 400 mm / 16" | 1 | 2240 mm / 7' - 4" |
SV 500-1300 | 500 mm / 20" | 1 | 1840 mm / 6' |
SV 600-1600 | 600 mm / 24" | 1 | 2240 mm / 7' - 4" |
SV 600-1800 | 600 mm / 24" | 1 | 2440 mm / 8' |
Multi Belt | |||
SV X2/300-1900 | 300 mm / 12" | 2 | 2240 mm / 7' - 4" |
SV X3/300-2600 | 300 mm / 12" | 3 | 2940 mm / 9' - 8" |
SV X2/400-2186 | 400 mm / 16" | 2 | 2626 mm / 8' - 7" |
SV X2/500-2386 | 500 mm / 20" | 2 | 2926 mm / 9' - 7" |
Material
- Dry use
- Wipe down (R)
- Wash down economic (CR)
- Wash down total (RS)
-
Leaflet SpiralVeyor SV-Series (EN) (.pdf)
-
Leaflet SpiralVeyor SV-Series (US) (.pdf)
-
Leaflet SpiralVeyor SV- Series (DE) (.pdf)
-
Leaflet SpiralVeyor SV-Series (JP) (.pdf)
-
Specification form SpiralVeyor SV-series (US) (.pdf)
-
Specification form SpiralVeyor SV-series (EN) (.pdf)
AmbaFlex as inventor of the spiral conveyor and with over 32,000 machines in the market is by far the most experienced party. These experiences are boiled down into market and application-specific PreDefined Configurations that exactly suit to our customers' needs.
For further details, specifications and prices please feel free to request more information here.
